PERMANENT BRAND

MT-FC71T-1

CORRESPONDING TO AWS E71T-1

CORRESPONDING TO JIS YFW-C50DR

CO2 FLUX CORED WIRES

Description:

MT-FC71T-1 is of oxide of titanium type slag kind CO₂flux cored wires for all positions welding inclusive of vertical down. The arc is stable with little spatter. The welds have smooth appearance. The slag is easy to remove and smoke little. It has excellent welding technological performances.

Applications:

For welding Iow carbon steel and 50kg/m class high tensile steel. It is widely used for welding structures of ships, bridges, buildings, stored tanks and steel beams etc.

Note on usage:

1.Strictly control the content of impurities in CO₂ , guarantee the purity of CO₂

2.The flow of CO₂is normally 20-251/min, when welding.

3.The outer length of wire should be controlled within 15-25mm.

Typical Chemical Composition Of Weld

Metal()

Typical: C(0.07) Mn(1.25) Si(0.36) S(0.010)

P(0.017)

Typical Mechanical Properties Od Weld Metal

TenSile Strength:570

Yield Strength:490

Elongation():28

Charpy V Impact Value (-18):90J

Packing:

In Cartons Of 15kgs net each
