Malleable Iron Pipe Fittings

THERADS:BS21

The fittings are mainly divided into plain or Beaded, Galvanized or Black. The outlets vary from 1/2” to 6” Mechanical Properties:

Tensile strength≥33kg/mm²

Elongation Rate≥8%

Hardness≤HB.163

Hydraulic Test: Test Pressure:25kg/cm²(=355lbs./in ²)

Working pressure: 16kg/cm²(=227lbs./in ²)

Our fittings are suitable for joining water, steam, gas and oil pipes. Universally popular in the world for their superior quality and moderate  price.

ORDERING INSTRUCTION

1. To state clearly Fig. No., Size, Quantity in piece and Galvanized or Black

2. Reducing fittings are charged are the price for the larger outlet.

3. Price list given in this catalogue is international basic price which are understood for 100 pieces in U.S.  Dollar and our final price offered for each order is to be valued after discount.

4. Any other sized and figures unillustrated in this catalogue can be supplied on application.
